The V-type mixer series products are high-efficiency asymmetric mixers, which are suitable for mixing powder or granular materials in industries such as chemical, food, pharmaceutical, feed, ceramics, metallurgy, etc. The machine has a reasonable and simple structure, operates in a closed manner, and is easy to feed and unload. The cylinder body is made of stainless steel material (manually or vacuum fed), which is easy to clean.

二、 Detailed parameters:
Model Full Capacity (m3)     Load Factor Maximum Load Capacity (L) Length (mm) Width (mm) Height (mm) Discharge Port (mm) Rotation Height (mm) Cylinder Speed (rpm) Motor Power (Kw) Whole Machine Weight (Kg)
VH-0.1 0.1 0.4 40 1650 500 1550 Φ80 1600 12 0.75 180
VH-0.3 0.3 0.4 120 1900 600 1750 Φ100 1900 12 1.1 350
VH-0.5 0.5 0.4 200 2300 700 2100 Φ150 2250 9 1.5 550
VH-1.0 1.0 0.4 400 2700 1000 2500 Φ150 2700 9 2.2 1000
VH-1.5 1.5 0.4 600 3000 1000 2600 Φ200 2900 8 3.0 1100
VH-2.0 2.0 0.4 800 3200 1200 3100 Φ200 3250 8 4.0 1500
VH-2.5 2.5 0.4 1000 3950 1500 3550 Φ200 3800 7 5.5 1700
VH-3.0 3.0 0.4 1200 4100 1500 3600 Φ200 3850 6 7.5 1800

三、 Performance characteristics:

The V-type mixer is mainly capable of uniformly mixing finer powders or materials with lower content of a certain main material. It uses two asymmetric material cylinders and gravity mixing to continuously gather and disperse materials inside the cylinder. Generally, after about 5-15 minutes of mixing, two or more types are fully mixed evenly, especially suitable for mixing two or more types of powder or granular materials with large differences in specific gravity. The mixing uniformity reaches over 99%. The inner and outer walls of the mixing cylinder are precision polished, with a smooth, flat surface, no dead corners, and easy cleaning.
The mixing drum consists of two asymmetric cylinders, which are formed by circular welding of high-quality stainless steel plate rings of δ 3mm304. The two ends of the V-shaped mixing drum are equipped with elliptical heads, and feeding ports are installed on both heads, which is more conducive to cleaning the drum after the materials are mixed.
The transmission system consists of a motor, a reducer, a sprocket, bearings, a transmission shaft, and other parts. The transmission shaft is fixed and welded to the cylinder wall and reinforced with a δ 6.0mm steel plate. It has the characteristics of no vibration, no eccentricity, low noise, easy maintenance, long service life, and smooth operation during operation.
The frame of the mixer is welded with channel steel, which is firmly welded. The outer shell of the frame is made of 304 stainless steel, with a smooth surface and no scratches. The transmission frame has movable doors at both ends for easy maintenance and repair.
The electrical control is precise and sensitive, and the mixing time is controlled by a digital time relay. The mixing time is set according to the actual production process requirements of the mixing. The feeding and discharging are done using a jog button, which moves the cylinder to the appropriate loading (or discharging) position for material feeding and discharging. Reduced labor intensity and improved production efficiency.
The feeding port is a movable cover plate, which is pressed tightly with a lever. The sealing is made of edible silicone rubber sealing strip, which is pollution-free and easy to operate.
The discharge port adopts stainless steel butterfly valve, which has good sealing effect and no leakage. Easy to operate.
This machine has a compact structure, small footprint, beautiful appearance, easy operation, and uniform mixing.
The whole machine complies with the national drug "GMP" standard.
