一、 Product Introduction:
Widely used in the pharmaceutical, chemical, food, metallurgical, light industry, and scientific research institutions, it can mix powdered and granular materials with good fluidity very evenly, so that the mixed materials can reach a good mixing state.

二、 Technical parameters:

Machine model, mixing cylinder, volume, loading capacity, loading weight, spindle speed, motor power, machine size, weight

GRT-5                 5L 4L 5L 24 0.37kw 300x1000x1000mm 150KG
GRT-100 100L 80L 80L 15 1.5kw 1200x1800x1500mm 500KG
GRT-200 200L 150L 150L 12 3kw 1300x1600x1500mm 750KG
GRT-400 400L 300L 200L 10 4kw 1500x2200x1500mm 1200KG
GRT-600 600L 450L 300L 10 5.5kw 1800x2500x1650mm 1500KG
GRT-800 800L 600L 400L 10 7.2kw 1900x2400x2100mm 1650KG
GRT-1000 1000L 750L 500L 10 11kw 1950x2500x2400mm 1800KG

GRT-1500 1500L 1200L 750L 10 11kw 2600x2500x2500mm 2500KG

三、 Machine features:
1. Due to the multi-directional movement of the mixing barrel, the materials inside the barrel cross the mixing points, resulting in a high mixing effect with a uniformity of over 99.9% and a loading coefficient of 0.9 (0.4-0.6 for ordinary mixers). The mixing time is short and the efficiency is high.
2. The mixing barrel of this machine has a unique design, with the inner wall of the barrel finely polished, no dead corners, no material pollution, easy discharge, easy cleaning, and simple operation.
